• การสั่งทำ
• Precision Guarantee

• Solid Stream Spray Nozzles (Two Orifices)

2CCP

Operating pressure:0.3-3 MPa
Spray capacity:1.68–3.42 L/min (1 MPa)
Spreading angle:10–25°
Material:S303

• การสั่งทำ
• Ceramic Orifice

• Paper Trimming Nozzles (Two Orifices)

2CM-FB

Operating pressure:0.5-3 MPa
Spray capacity:0.24–0.67 L/min (1 MPa)
Material:S303

• การสั่งทำ
• Ceramic Orifice
• Precision Guarantee

• Solid Stream Spray Nozzles (Two Orifices)

2CP

Operating pressure:0.3-3 MPa
Spray capacity:0.86–3.42 L/min (1 MPa)
Spreading angle:10–25°
Material:S303

• การสั่งทำ
• Precision Guarantee

• Solid Stream Spray Nozzles (Seven Orifices)

7CCP

Operating pressure:0.3-3 MPa
Spray capacity:5.88–11.9 L/min (1 MPa)
Spreading angle:15°
Material:S303

• การสั่งทำ
• Ceramic Orifice
• Precision Guarantee

• Solid Stream Spray Nozzles (Seven Orifices)

7CP

Operating pressure:0.3-3 MPa
Spray capacity:3.01–11.9 L/min (1 MPa)
Spreading angle:15°
Material:S303

• การสั่งทำ

• 7-outlet Connecting Adaptor

7-outlet Adaptor

Max. operating pressure:1.0 MPa
Heat resistance:80℃
Outlet thread size:Rc1/8
Material:FRPP

• Precision Guarantee

• Full Cone Spray Nozzles (Clog-resistant)

AJP-PPS

Spray capacity:4.00–16.0 L/min (0.2 MPa)
Spray angle:75–85°
Material:PPS
Free passage diameter:2.2–4.8 mm

• ARS Filter
• Filtration Device

• Automatic Strainer

ARS (Auto Reverse Self-cleaning Filter)

Max. filtration capacity:150–2,500 L/min
Types of screen:Metal wire screen , Wedge wire screen

• การสั่งทำ

• Detergent Foam Spray Nozzles (Solid Stream)

AWCC

Operating pressure:0.1-0.6 MPa
Spray capacity:1.00-5.00 L/min (0.3 MPa)
Material:S303

• การสั่งทำ

• Detergent Foam Spray Nozzles (Flat Spray Pattern)

AWVV

Operating pressure:0.1-0.6 MPa
Spray capacity:1.00-5.00 L/min (0.3 MPa)
Spray angle:80°, 100°
Material:S303

• การสั่งทำ
• Clog Resistant

• Fine Fog, Flat Spray Nozzles (Large Capacity)

BAVV

Mean droplet diameter:30–100 μm
Spray capacity:10–200 L/hr
Spray angle:60°
Material:S303, S304

• สินค้าสั่งทำ
• Precision Guarantee

• Wide-angle Full Cone Spray Nozzles

BBXP

Spray capacity:1.50–1200 L/min
Spray angle:120°
Material:S303, S316
Free passage diameter:0.7–21.7 mm

• Precision Guarantee

• Wide-angle Full Cone Spray Nozzles

BBXP-PVC

Spray capacity:3.00 L/min (0.2 MPa)
Spray angle:120°
Material:PVC
Free passage diameter:1.5 mm

• Precision Guarantee

• Wide-angle Full Cone Spray Nozzles

BBXP-PVDF

Spray capacity:0.80–2.00 ℓ/min (0.2 MPa)
Spray angle:120°
Material:PVDF
Free passage diameter:0.5–1.2 mm

• Spray Control

• Fine Fog, Full Cone Spray Nozzles

BIMJ

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70°, 20°
Material:S303

• Spray Control

• Spray Gun Unit with BIM Nozzles

BIMV

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:45°, 80°, 110°
Material:S303

• Spray Gun Unit with BIM Nozzles

BIM-GUN

• การสั่งทำ
• Self-cleaning

• Spray Headers with Nozzle Cleaning Function

BRASIKan

Standard pressure:0.3 MPa
Free passage diameter:1.3–2.9 mm
Material:S303, S316L, TN

• Compact
• Spray Control

• Fine Fog, Flat Spray Nozzles

CBIMV

Mean droplet diameter:20-100 μm
Spray capacity:0.25–38.5 L/hr
Spray angle:45°, 80°, 110°
Material:S303

• Precision Guarantee

• Solid Stream Spray Nozzles

CCP

Operating pressure:0.1-3.5 MPa
Spray capacity:13.6–104 L/min (3 MPa)
Free passage diameter:2.0–5.4 mm
Material:S303

• Precision Guarantee

• Solid Stream Spray Nozzles (Convex Round Inlet)

CCRP

Operating pressure:0.3-3 MPa
Spray capacity:0.37–5.84 L/min (1 MPa)
Material:S303

• สินค้าสั่งทำ
• Ceramic Orifice

• Paper Trimming Nozzles

CM

Operating pressure:0.5-5 MPa
Spray capacity:0.016–3.03 L/min (1 MPa)
Material:S303

• Ceramic Orifice

• Paper Trimming Nozzles

CM-FB

Operating pressure:0.5-5 MPa
Spray capacity:0.12–0.49 L/min (1 MPa)
Material:S303

• Ceramic Orifice

• Paper Trimming Nozzles

CMP-T

Operating pressure:0.5-5 MPa
Spray capacity:0.14–1.34 L/min (1 MPa)
Material:S303

• Ceramic Orifice
• Precision Guarantee

• Solid Stream Spray Nozzles

CP

Operating pressure:0.1-15 MPa
Spray capacity:2.47–104 L/min (3 MPa)
Free passage diameter:0.8–5.4 mm
Material:S303

• การสั่งทำ
• Ceramic Orifice

• Solid Stream Spray Nozzles (Small Orifice Diameters)

CP (Small Orifice Diameters)

Operating pressure:1-15 MPa
Spray capacity:0.020–1.27 L/min (1 MPa)
Material:S303

• Ceramic Orifice

• Solid Stream Spray Nozzles (Convex Round Inlet)

CRP

Operating pressure:0.3-3 MPa
Spray capacity:0.37–5.84 L/min (1 MPa)
Material:S303

• สินค้าสั่งทำ

• Paper Trimming Nozzles

CTM

Operating pressure:0.5-5 MPa
Spray capacity:0.06–3.03 L/min (1 MPa)
Material:S303

• Precision Guarantee

• Flat Spray Nozzles (Coin-shaped)

CVVP

Operating pressure:0.05-2 MPa
Spray capacity:1.00–8.00 L/min (0.3 MPa)
Spray angle:65°, 80°, 90°
Material:S303

• การสั่งทำ
• Precision Guarantee

• Ultra-Thick Even Flat Spray Nozzles

DDRP

Operating pressure:0.05-2 MPa
Spray capacity:5.00-100 L/min (0.3 MPa)
Spray angle:90°, 115°
Material:S303

• การสั่งทำ
• Precision Guarantee

• Even Flat Spray Nozzles

EJVV

Operating pressure:0.25-2 MPa
Spray capacity:2.00-12.0 L/min (0.3 MPa)
Spray angle:80°, 90°
Material:S303, B

• 180° downward
• 180° upward
• 360°

• 2D Rotational Tank Cleaning Nozzles

ES

Spray capacity:4.0–803.3 L/min (0.1–1.0 MPa)
Reach distance:Approx. 0.5–7.3m
Heat resistance:60℃
Material:S316L

• 180° downward
• 180° upward
• 360°

• 2D Rotational Tank Cleaning Nozzles

ES-PTFE

Spray capacity:12.2–194 L/min (0.05–0.5 MPa)
Reach distance:approx.1.5–4 m
Heat resistance:93℃
Material:PTFE

• 360°

• 2D Rotational Tank Cleaning Nozzles

ESV-PTFE

Spray capacity:12.2–194 L/min (0.05–0.5 MPa)
Reach distance:approx.1.1–4 m
Heat resistance:93℃
Material:PTFE

• Quick-detachable

• Spray Nozzle Connector (Quick-detachable)

INCO

Outlet thread size:Rc1/4, Rc3/8, Rc1/2
Material:PP, PPS

• Precision Guarantee
• Quick-detachable

• Full Cone Spray Nozzles (Quick-detachable)

INJJX

Spray capacity:1.00–6.00 L/min (0.2 MPa)
Spray angle:65°–75°
Material:PP
Free passage diameter:0.8–2.0 mm

• Precision Guarantee
• Quick-detachable

• Full Cone Spray Nozzles (Quick-detachable)

INJJX-SS

Spray capacity:1.00–6.00 L/min (0.2 MPa)
Spray angle:65°–75°
Material:S303
Free passage diameter:0.7–1.7 mm

• Precision Guarantee
• Quick-detachable

• Full Cone Spray Nozzles (Quick-detachable)

INJJX-Y

Spray capacity:1.00–5.00 L/min (0.2 MPa)
Spray angle:65°
Material:PP
Free passage diameter:0.8–2.0 mm

• Precision Guarantee
• Quick-detachable

• Off-center Even Flat Spray Nozzles (Quick-detachable)

INOVVE

Operating pressure:0.15-0.7 MPa
Spray capacity:3.00-5.00 L/min (0.3 MPa)
Spray angle:45°
Material:PP, PPS

• Precision Guarantee
• Quick-detachable

• Quick-installation Nozzles

INQB

Operating pressure:0.1-0.4 MPa
Spray capacity:8.00–39.0 L/min(0.3 MPa)
Spray angle:40°, 65°, 80°
Material:FRPP

• Ceramic Orifice
• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INV

Operating pressure:0.05-2 MPa
Spray capacity:2.0–8.0 L/min (0.3 MPa)
Spray angle:50°, 65°, 80°, 90°, 115°
Material:S303

• Ceramic Orifice
• Precision Guarantee
• Quick-detachable

• Even Flat Spray Nozzles (Quick-detachable)

INVE

Operating pressure:0.05-2 MPa
Spray capacity:1.9–15.7 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INVV (Plastic)

Operating pressure:0.05-0.7 MPa
Spray capacity:0.50–5.00 L/min (0.3 MPa)
Spray angle:50°, 65°, 90°, 115°
Material:PP

• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INVV-SS (Stainless Steel)

Operating pressure:0.05-2 MPa
Spray capacity:1.50–20.0 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• Quick-detachable

• Spray Header with Quick-Detachable Nozzles

INVVEA

Mean droplet diameter:20–400 μm
Spray capacity:0.30–3.0 L/min
Spray angle:60°
Material:PP, PPS, HTPVC

• สินค้าที่เลิกผลิตแล้ว
• Precision Guarantee
• Quick-detachable

• Quick-installation Nozzles

ISQB

Operating pressure:0.1-0.4 MPa
Operating pressure:8.00–39.0 L/min(0.3 MPa)
Spray capacity:40°, 65°, 80°
Spray angle:FRPP

• Ceramic Orifice
• Precision Guarantee

• Full Cone Spray Nozzles

J

Spray capacity:0.09–1.40 L/min
Spray angle:70°
Material:S303
Free passage diameter:0.15–0.9 mm

• 360°
• JET ATTACKER

• 3D Rotational Tank Cleaning Nozzles

JA3 (JET ATTACKER)

Spray capacity:12–70 L/min (1.0–3.0 MPa)
Reach distance:approx. 6–9m
Heat resistance:60℃
Material:S304

• 360°
• JET ATTACKER

• 3D Rotational Tank Cleaning Nozzles

JA3 (JET ATTACKER / Low-pressure Use)

Spray capacity:24–82 L/min (0.3–1.2 MPa)
Reach distance:approx. 2–7 m
Heat resistance:60℃
Material:S304

• JET ATTACKER

• 2D Rotational Tank Cleaning Nozzles

JA2 (JET ATTACKER)

Spray capacity:14–253.0 L/min (1.0–3.0 MPa)
Heat resistance:60℃
Material:S304
