• การสั่งทำ
• Precision Guarantee

• Seven-head Full Cone Spray Nozzles

7JJXP

Spray capacity:7.00–315 L/min (0.2 MPa)
Spray angle:175–215°
Material:S303
Free passage diameter:0.8–4.7 mm

• Precision Guarantee

• Seven-head Full Cone Spray Nozzles

7KB

Spray capacity:0.23–10.9 L/min (0.7 MPa)
Spray angle:180°
Material:S303
Free passage diameter:0.15–0.60 mm

• Precision Guarantee

• Hollow Cone Spray Nozzles

AAP

Operating pressure:1.00–23.0 L/min (0.2 MPa)
Spray capacity:75–80°
Material:S304
Free passage diameter:2.0–8.0 mm

• Precision Guarantee

• Full Cone Spray Nozzles (Clog-resistant)

AJP

Spray capacity:2.00–250 L/min (0.2 MPa)
Spray angle:75–90°
Material:S303, S304, SCS13
Free passage diameter:1.6–22.3 mm

• การสั่งทำ
• Precision Guarantee

• Full Cone Spray Nozzles (Alumina Ceramic)

AJP-AL92

Spray capacity:18.0–250 L/min (0.2 MPa)
Spray angle:85–90°
Material:92％ Alumina
Free passage diameter:5.1–21.3 mm

• การสั่งทำ

• Impinging-type Fine Fog Nozzles

AKIJet

Mean droplet diameter:10–120 μm
Spray capacity:10–450 L/hr
Spray width:140–780 mm
Material:S303 equivalent, S303, SCS14, S316

• การสั่งทำ
• Precision Guarantee

• Hollow Cone Spray Nozzles (Alumina Ceramic)

AP-AL92

Spray capacity:14.0–600 L/min (0.2 MPa)
Spray angle:80–85°
Material:92％ Alumina
Free passage diameter:6.8–39.6 mm

• การสั่งทำ
• Clog Resistant

• Fine Fog, Flat Spray Nozzles (Large Capacity)

BAVV

Mean droplet diameter:30–100 μm
Spray capacity:10–200 L/hr
Spray angle:60°
Material:S303, S304

• Spray Control

• Fine Fog, Full Cone Spray Nozzles

BIMJ

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70°, 20°
Material:S303

• Clog Resistant

• Flat Spray Nozzles

DOVVA-G

Mean droplet diameter:80–120 μm
Spray capacity:1.0–50 L/min
Spray angle:55°, 70°
Material:S316L, S304

• Large Capacity Fine Fog Spray Nozzles (Large Spray Capacity)

GSIMⅡ

Mean droplet diameter:30–80 μm
Spray capacity:15–2,000 L/hr
Spray angle:20°, 60°
Material:S316L, S303

• Return-flow Nozzle

• Spillback Nozzles

GSPB

Spray capacity:1.0–4.0 MPa
Spray angle:90°, 130°
Material:Tungsten carbide
Free passage diameter:5.7 mm

• Ceramic Orifice
• Precision Guarantee

• Full Cone Spray Nozzles

J

Spray capacity:0.09–1.40 L/min
Spray angle:70°
Material:S303
Free passage diameter:0.15–0.9 mm

• Clog Resistant

• Full Cone Spray Nozzles

JJA

Mean droplet diameter:150–650 μm
Spray capacity:1.1–24.0 L/min
Material:S316L, S304

• Full Cone Spray Nozzles

JJHP

Spray capacity:340–840 L/min (0.05 MPa)
Spray angle:75–105°
Material:S316L
Free passage diameter:10–15.5 mm

• สินค้าสั่งทำ
• Precision Guarantee

• Full Cone Spray Nozzles

JJXP

Spray capacity:0.50–1200 L/min (0.2 MPa)
Spray angle:55–105°
Material:S303, S316
Free passage diameter:0.4–20.0 mm

• Steam

• Steam-driven Spray Nozzles

JOKIJet

Spray capacity:10–1,200 L/hr
Material:S316L, S304

• การสั่งทำ
• Ceramic Orifice
• Precision Guarantee

• Full Cone Spray Nozzles

JUP

Spray capacity:3.00-90.0 L/min (0.2 MPa)
Spray angle:60-85°
Material:S303, S316
Free passage diameter:1.2-5.0 mm

• การสั่งทำ
• Precision Guarantee

• Full Cone Spray Nozzles (Alumina Ceramic)

JUXP-AL92

Spray capacity:23.0–700 L/min (0.2 MPa)
Spray angle:75–100°
Material:92％ Alumina
Free passage diameter:4.7–17.8 mm

• Full Cone Spray Nozzles (Blower Air Type)

LSIM

Mean droplet diameter:40–80 μm
Spray capacity:100–1,000 L/hr
Spray angle:20°
Material:S316L, S304

• Return-flow Nozzle

• Spillback Nozzles

SPB

Supply pressure:1.0–4.0 MPa
Spray angle:60ﾟ, 85ﾟ
Material:S316
Free passage diameter:1.3–3.0 mm

• สินค้าสั่งทำ
• Precision Guarantee

• Square Spray Nozzles

SSXP

Spray capacity:2.00–700 L/min (0.2 MPa)
Spray angle:90–100°
Material:S303
Free passage diameter:0.9–17.1 mm

• การสั่งทำ
• Precision Guarantee

• Spray Nozzles for Spraying Slurries

TAA

Spray capacity:200–1,200 L/min (0.07 MPa)
Spray angle:67–80°
Material:SiC
Free passage diameter:28–68 mm

• การสั่งทำ
• Precision Guarantee

• Large Capacity Full Cone Spray Nozzles

TJJX

Spray capacity:200–1,200 L/min (0.2 MPa)
Spray angle:90–100°
Material:S304, S316, SCS13, SCS14
Free passage diameter:28–43 mm

• การสั่งทำ

• Wide-angle Full Cone Spray Nozzles (Multi-orifice)

TSP

Spray capacity:15.0–60.1 L/min (5 MPa)
Material:S303
Free passage diameter:0.4–0.8 mm

• การสั่งทำ

• Spray Nozzles for Spraying Slurries (Two-way)

TWAA

Spray capacity:200–1,200 L/min (0.07 MPa)
Spray angle:67–80°
Material:SiC
Free passage diameter:28–68 mm

• Full Cone Spray Nozzles

UZUJP

Spray capacity:75–220 L/min (0.1 MPa)
Spray angle:120°, 170°
Material:SCS16
Free passage diameter:4.3–7.3 mm

• CFD
• Gas Conditioning Tower

• Complete Evaporation

Flue Gas Cooling System
