• การสั่งทำ
• Precision Guarantee

• Solid Stream Spray Nozzles (Two Orifices)

2CCP

Operating pressure:0.3-3 MPa
Spray capacity:1.68–3.42 L/min (1 MPa)
Spreading angle:10–25°
Material:S303

• การสั่งทำ
• Ceramic Orifice
• Precision Guarantee

• Solid Stream Spray Nozzles (Two Orifices)

2CP

Operating pressure:0.3-3 MPa
Spray capacity:0.86–3.42 L/min (1 MPa)
Spreading angle:10–25°
Material:S303

• การสั่งทำ
• Precision Guarantee

• Solid Stream Spray Nozzles (Seven Orifices)

7CCP

Operating pressure:0.3-3 MPa
Spray capacity:5.88–11.9 L/min (1 MPa)
Spreading angle:15°
Material:S303

• การสั่งทำ
• Ceramic Orifice
• Precision Guarantee

• Solid Stream Spray Nozzles (Seven Orifices)

7CP

Operating pressure:0.3-3 MPa
Spray capacity:3.01–11.9 L/min (1 MPa)
Spreading angle:15°
Material:S303

• Dry Fog
• Pneumatic Humidification
• With Caster Wheels

• Portable Humidifier Unit

AE-T Set (Portable Dry Fog Humidifier Set)

Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–14.4 L/hr (03C)
Air consumption:22–172 NL/min (03C)

• Dry Fog
• Pneumatic Humidification

• Industrial Humidification System

AirAKI

• Method: Pneumatic humidification
• แรงดันในการใช้งาน : 0.2–0.5 Mpa
• ความจุในการพ่น : 1.3–4.5 L/hr (ต่อหัวฉีด)
• จำนวนอากาศที่ใช้ : 22–54 L/min, Normal (ต่อหัวฉีด)

• Hydraulic Humidification
• Semi-Dry Fog

• Humidification System for Industrial Use

AirULM

• ระบบ Hydraulic สามารถทำความชื้นได้ครอบคลุมทุกพื้นที่ในโรงงาน
• สามารถทำงานด้วยปั๊มแรงงานสูงโดยไม่ต้องใช้แรงลมช่วย
• สามารถช่วยลดค่าใช้จ่ายได้เมื่อเทียบกับการทำความชื้นในรูปแบบอื่น

• การสั่งทำ

• Impinging-type Fine Fog Nozzles

AKIJet

Mean droplet diameter:10–120 μm
Spray capacity:10–450 L/hr
Spray width:140–780 mm
Material:S303 equivalent, S303, SCS14, S316

• Dry Fog
• Pneumatic Humidification

• Dry Fog Humidifier

AKIMist-E Humidifier

Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–4.5 L/hr (per nozzle)
Air consumption:22–54 NL/min (per nozzle)

• ARS Filter
• Filtration Device

• Automatic Strainer

ARS (Auto Reverse Self-cleaning Filter)

Max. filtration capacity:150–2,500 L/min
Types of screen:Metal wire screen , Wedge wire screen

• Hydraulic Humidification
• Semi-Dry Fog

• Humidification System for Office Use

AU-KIT

• แก้ปัญหาความยุ่งยากในการเติมน้ำทุกวันด้วยระบบเติมน้ำอัตโนมัติ
• ลดการเกิดผงสีขาวบริเวณเครื่องทำความชื้น
• สามารถใช้ระบบอัตโนมัติในการทำความชื้นในเวลาที่ต้องการ

• Compressor
• With Caster Wheels

• Detergent Foam Spray Nozzle Unit

AWA Cart

Spray capacity:1.7 L/min
Air consumption:22 NL/min
Reach distance:3.6 m
Material:S316L

• การสั่งทำ

• Detergent Foam Spray Nozzles (Solid Stream)

AWCC

Operating pressure:0.1-0.6 MPa
Spray capacity:1.00-5.00 L/min (0.3 MPa)
Material:S303

• การสั่งทำ

• Detergent Foam Spray Nozzles (Flat Spray Pattern)

AWVV

Operating pressure:0.1-0.6 MPa
Spray capacity:1.00-5.00 L/min (0.3 MPa)
Spray angle:80°, 100°
Material:S303

• การสั่งทำ
• Clog Resistant

• Fine Fog, Flat Spray Nozzles (Large Capacity)

BAVV

Mean droplet diameter:30–100 μm
Spray capacity:10–200 L/hr
Spray angle:60°
Material:S303, S304

• สินค้าสั่งทำ
• Precision Guarantee

• Wide-angle Full Cone Spray Nozzles

BBXP

Spray capacity:1.50–1200 L/min
Spray angle:120°
Material:S303, S316
Free passage diameter:0.7–21.7 mm

• Spray Control

• Fine Fog, Full Cone Spray Nozzles

BIMJ

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70°, 20°
Material:S303

• Spray Control

• Fine Fog, Hollow Cone Spray Nozzles

BIMK

Mean droplet diameter:20-100 μm
Spray capacity:2.0–107 L/hr
Spray angle:60°
Material:S303

• Spray Control
• Suction

• Fine Fog, Hollow Cone Spray Nozzles (Suction Type)

BIMK.S

Mean droplet diameter:20-30 μm
Spray capacity:1.4–5.5 L/hr
Spray angle:60°
Material:S303

• Spray Control

• Spray Gun Unit with BIM Nozzles

BIMV

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:45°, 80°, 110°
Material:S303

• Spray Control
• Suction

• Fine Fog, Flat Spray Nozzles (Suction Type)

BIMV.S

Mean droplet diameter:20-30 μm
Spray capacity:0.5–5.5 L/hr
Spray angle:80°
Material:S303

• Spray Gun Unit with BIM Nozzles

BIM-GUN

• Compact
• Spray Control

• Fine Fog, Flat Spray Nozzles

CBIMJ

Mean droplet diameter:20-100 μm
Spray capacity:0.25–38.5 L/hr
Spray angle:20°
Material:S303

• Compact
• Spray Control

• Fine Fog, Hollow Cone Spray Nozzles

CBIMK

Mean droplet diameter:20-100 μm
Spray capacity:2.0–38.5 L/hr
Spray angle:60°
Material:S303

• Compact
• Spray Control
• Suction

• Fine Fog, Hollow Cone Spray Nozzles (Suction Type)

CBIMK.S

Mean droplet diameter:20-30 μm
Spray capacity:1.4–5.5 L/hr
Spray angle:60°
Material:S303

• Compact
• Spray Control

• Fine Fog, Flat Spray Nozzles

CBIMV

Mean droplet diameter:20-100 μm
Spray capacity:0.25–38.5 L/hr
Spray angle:45°, 80°, 110°
Material:S303

• Compact
• Spray Control
• Suction

• Fine Fog, Flat Spray Nozzles (Suction Type)

CBIMV.S

Mean droplet diameter:20-30 μm
Spray capacity:0.1–5.5 L/hr
Spray angle:80°
Material:S303

• Precision Guarantee

• Solid Stream Spray Nozzles

CCP

Operating pressure:0.1-3.5 MPa
Spray capacity:13.6–104 L/min (3 MPa)
Free passage diameter:2.0–5.4 mm
Material:S303

• Compressor

• Solid Stream Air Nozzles

CCP-A

Air consumption:35–215 NL/min (0.3 MPa)
Max. operating pressure:1.0 MPa
Noise level:66–84 dBA (0.3 MPa)
Material:S303

• Precision Guarantee

• Solid Stream Spray Nozzles (Convex Round Inlet)

CCRP

Operating pressure:0.3-3 MPa
Spray capacity:0.37–5.84 L/min (1 MPa)
Material:S303

• Ceramic Orifice
• Precision Guarantee

• Solid Stream Spray Nozzles

CP

Operating pressure:0.1-15 MPa
Spray capacity:2.47–104 L/min (3 MPa)
Free passage diameter:0.8–5.4 mm
Material:S303

• การสั่งทำ
• Ceramic Orifice

• Solid Stream Spray Nozzles (Small Orifice Diameters)

CP (Small Orifice Diameters)

Operating pressure:1-15 MPa
Spray capacity:0.020–1.27 L/min (1 MPa)
Material:S303

• Ceramic Orifice

• Solid Stream Spray Nozzles (Convex Round Inlet)

CRP

Operating pressure:0.3-3 MPa
Spray capacity:0.37–5.84 L/min (1 MPa)
Material:S303

• Precision Guarantee

• Flat Spray Nozzles (Coin-shaped)

CVVP

Operating pressure:0.05-2 MPa
Spray capacity:1.00–8.00 L/min (0.3 MPa)
Spray angle:65°, 80°, 90°
Material:S303

• สินค้าสั่งทำ
• Ceramic Orifice
• Precision Guarantee

• Descaling Nozzles

DSP

Operating pressure:3-20 MPa
Spray capacity:5.59–86.5 L/min (5 MPa)
Spray angle:12°, 15°
Material:S303

• Compressor

• Air Booster Nozzles

EJA

Air consumption:150–750 NL/min (0.3 MPa)
Max. operating pressure:0.6 MPa
Noise level:83 dBA (0.3 MPa)
Material:S303

• 180° downward
• 180° upward
• 360°

• 2D Rotational Tank Cleaning Nozzles

ES

Spray capacity:4.0–803.3 L/min (0.1–1.0 MPa)
Reach distance:Approx. 0.5–7.3m
Heat resistance:60℃
Material:S316L

• 180° downward
• 180° upward
• 360°

• 2D Rotational Tank Cleaning Nozzles

ES-PTFE

Spray capacity:12.2–194 L/min (0.05–0.5 MPa)
Reach distance:approx.1.5–4 m
Heat resistance:93℃
Material:PTFE

• 360°

• 2D Rotational Tank Cleaning Nozzles

ESV-PTFE

Spray capacity:12.2–194 L/min (0.05–0.5 MPa)
Reach distance:approx.1.1–4 m
Heat resistance:93℃
Material:PTFE

• Blower
• Compressor

• Flexible Tubes

FT

Max. operating pressure:0.3 MPa
Heat resistance:65℃
出Outlet thread size:Rc1/8, Rc1/4
Material:POM

• Compressor

• Flat Air Nozzles

HF

Air consumption:300–550 NL/min (0.3 MPa)
Max. operating pressure:1.0 MPa
Noise level:81 dBA
Material:S303

• Quick-detachable

• Spray Nozzle Connector (Quick-detachable)

INCO

Outlet thread size:Rc1/4, Rc3/8, Rc1/2
Material:PP, PPS

• Precision Guarantee
• Quick-detachable

• Off-center Even Flat Spray Nozzles (Quick-detachable)

INOVVE

Operating pressure:0.15-0.7 MPa
Spray capacity:3.00-5.00 L/min (0.3 MPa)
Spray angle:45°
Material:PP, PPS

• Precision Guarantee
• Quick-detachable

• Quick-installation Nozzles

INQB

Operating pressure:0.1-0.4 MPa
Spray capacity:8.00–39.0 L/min(0.3 MPa)
Spray angle:40°, 65°, 80°
Material:FRPP

• Ceramic Orifice
• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INV

Operating pressure:0.05-2 MPa
Spray capacity:2.0–8.0 L/min (0.3 MPa)
Spray angle:50°, 65°, 80°, 90°, 115°
Material:S303

• Ceramic Orifice
• Precision Guarantee
• Quick-detachable

• Even Flat Spray Nozzles (Quick-detachable)

INVE

Operating pressure:0.05-2 MPa
Spray capacity:1.9–15.7 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INVV-SS (Stainless Steel)

Operating pressure:0.05-2 MPa
Spray capacity:1.50–20.0 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• สินค้าที่เลิกผลิตแล้ว
• Precision Guarantee
• Quick-detachable

• Quick-installation Nozzles

ISQB

Operating pressure:0.1-0.4 MPa
Operating pressure:8.00–39.0 L/min(0.3 MPa)
Spray capacity:40°, 65°, 80°
Spray angle:FRPP

• Ceramic Orifice
• Precision Guarantee

• Full Cone Spray Nozzles

J

Spray capacity:0.09–1.40 L/min
Spray angle:70°
Material:S303
Free passage diameter:0.15–0.9 mm

• 360°
• JET ATTACKER

• 3D Rotational Tank Cleaning Nozzles

JA3 (JET ATTACKER)

Spray capacity:12–70 L/min (1.0–3.0 MPa)
Reach distance:approx. 6–9m
Heat resistance:60℃
Material:S304
