• การสั่งทำ

• Impinging-type Fine Fog Nozzles

AKIJet

Mean droplet diameter:10–120 μm
Spray capacity:10–450 L/hr
Spray width:140–780 mm
Material:S303 equivalent, S303, SCS14, S316

• Compressor
• With Caster Wheels

• Detergent Foam Spray Nozzle Unit

AWA Cart

Spray capacity:1.7 L/min
Air consumption:22 NL/min
Reach distance:3.6 m
Material:S316L

• Spray Control

• Fine Fog, Full Cone Spray Nozzles

BIMJ

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70°, 20°
Material:S303

• Spray Control

• Fine Fog, Hollow Cone Spray Nozzles

BIMK

Mean droplet diameter:20-100 μm
Spray capacity:2.0–107 L/hr
Spray angle:60°
Material:S303

• Spray Control
• Suction

• Fine Fog, Hollow Cone Spray Nozzles (Suction Type)

BIMK.S

Mean droplet diameter:20-30 μm
Spray capacity:1.4–5.5 L/hr
Spray angle:60°
Material:S303

• Spray Control

• Spray Gun Unit with BIM Nozzles

BIMV

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:45°, 80°, 110°
Material:S303

• Spray Control
• Suction

• Fine Fog, Flat Spray Nozzles (Suction Type)

BIMV.S

Mean droplet diameter:20-30 μm
Spray capacity:0.5–5.5 L/hr
Spray angle:80°
Material:S303

• Spray Gun Unit with BIM Nozzles

BIM-GUN

• Compact
• Spray Control

• Fine Fog, Flat Spray Nozzles

CBIMJ

Mean droplet diameter:20-100 μm
Spray capacity:0.25–38.5 L/hr
Spray angle:20°
Material:S303

• Compact
• Spray Control

• Fine Fog, Hollow Cone Spray Nozzles

CBIMK

Mean droplet diameter:20-100 μm
Spray capacity:2.0–38.5 L/hr
Spray angle:60°
Material:S303

• Compact
• Spray Control
• Suction

• Fine Fog, Hollow Cone Spray Nozzles (Suction Type)

CBIMK.S

Mean droplet diameter:20-30 μm
Spray capacity:1.4–5.5 L/hr
Spray angle:60°
Material:S303

• Compact
• Spray Control

• Fine Fog, Flat Spray Nozzles

CBIMV

Mean droplet diameter:20-100 μm
Spray capacity:0.25–38.5 L/hr
Spray angle:45°, 80°, 110°
Material:S303

• Compact
• Spray Control
• Suction

• Fine Fog, Flat Spray Nozzles (Suction Type)

CBIMV.S

Mean droplet diameter:20-30 μm
Spray capacity:0.1–5.5 L/hr
Spray angle:80°
Material:S303

• สินค้าสั่งทำ

• Ejector Nozzles

EJX

Operating pressure:0.03-0.3 MPa
Supply water range:1.10–160 ℓ/min (0.1 MPa)
Discharge range:3.1–460 ℓ/min (0.1 MPa)
Material:S303, S304, PP, PVC

• การสั่งทำ

• Ejector Nozzles (High-velocity Type)

EJX-H

Operating pressure:0.03-0.3 MPa
Supply water range:5.80–64.0 L/min (0.1 MPa)
Discharge range:18.8–206 L/min (0.1 MPa)
Material:PP

• Precision Guarantee
• Quick-detachable

• Full Cone Spray Nozzles (Quick-detachable)

INJJX

Spray capacity:1.00–6.00 L/min (0.2 MPa)
Spray angle:65°–75°
Material:PP
Free passage diameter:0.8–2.0 mm

• Precision Guarantee
• Quick-detachable

• Full Cone Spray Nozzles (Quick-detachable)

INJJX-SS

Spray capacity:1.00–6.00 L/min (0.2 MPa)
Spray angle:65°–75°
Material:S303
Free passage diameter:0.7–1.7 mm

• Precision Guarantee
• Quick-detachable

• Full Cone Spray Nozzles (Quick-detachable)

INJJX-Y

Spray capacity:1.00–5.00 L/min (0.2 MPa)
Spray angle:65°
Material:PP
Free passage diameter:0.8–2.0 mm

• Precision Guarantee
• Quick-detachable

• Off-center Even Flat Spray Nozzles (Quick-detachable)

INOVVE

Operating pressure:0.15-0.7 MPa
Spray capacity:3.00-5.00 L/min (0.3 MPa)
Spray angle:45°
Material:PP, PPS

• Ceramic Orifice
• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INV

Operating pressure:0.05-2 MPa
Spray capacity:2.0–8.0 L/min (0.3 MPa)
Spray angle:50°, 65°, 80°, 90°, 115°
Material:S303

• Ceramic Orifice
• Precision Guarantee
• Quick-detachable

• Even Flat Spray Nozzles (Quick-detachable)

INVE

Operating pressure:0.05-2 MPa
Spray capacity:1.9–15.7 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INVV (Plastic)

Operating pressure:0.05-0.7 MPa
Spray capacity:0.50–5.00 L/min (0.3 MPa)
Spray angle:50°, 65°, 90°, 115°
Material:PP

• Precision Guarantee
• Quick-detachable

• Flat Spray Nozzles (Quick-detachable)

INVV-SS (Stainless Steel)

Operating pressure:0.05-2 MPa
Spray capacity:1.50–20.0 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• Precision Guarantee

• Full Cone Spray Nozzles

JJXP-HTPVC

Spray capacity:4.00–6.00 L/min (0.2 MPa)
Spray angle:65°–75°
Material:HTPVC
Free passage diameter:2.1 mm

• Precision Guarantee

• Full Cone Spray Nozzles

JJXP-PVC

Spray capacity:2.00 L/min (0.2 MPa)
Spray angle:75°
Material:PVC
Free passage diameter:1.5 mm

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles (Three-piece Structure)

K

Spray capacity:0.06-1.80 L/min (0.3 MPa)
Mean droplet diameter:80-380 μm
Material:S303
Free passage diameter:0.4-1.7 mm

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles

KB

Spray capacity:2.00–107 L/hr (0.7 MPa)
Mean droplet diameter:45–210 μm
Material:S303, B
Free passage diameter:0.15–0.60 mm

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles

KBN

Spray capacity:2.00–7.25 L/hr (0.3 MPa)
Mean droplet diameter:35–60 μm
Material:S303
Free passage diameter:0.2–0.4 mm

• สินค้าสั่งทำ
• Precision Guarantee

• Hollow Cone Spray Nozzles

KKBP

Spray capacity:0.50–2.00 L/min (0.3 MPa)
Spray angle:53–68°
Material:S303
Free passage diameter:1.0–1.8 mm

• Oil-free
• Precision Guarantee

• Wide-angle Flat Spray Nozzles (Ultra-low Pressure Type)

LYYP

Operating pressure:0.008-0.04 MPa
Operating pressure:0.20–1.00 L/min (0.3 MPa)
Spray capacity:70°, 80°, 90°, 100°, 110°, 120°
Spray angle:PVC

• Precision Guarantee

• Off-center Even Flat Spray Nozzles

OVVEP

Operating pressure:0.05-2 MPa
Operating pressure:20.0-30.0 L/min (0.3 MPa)
Spray capacity:45°, 60°
Spray angle:S303

• การสั่งทำ
• Compact
• Spray Control

• Ultra-compact, Low Flow Rate Full Cone Spray Nozzles

SCBIMJ

Mean droplet diameter:20-100 μm
Spray capacity:0.25–4.0 L/hr
Spray angle:20°
Material:S303

• การสั่งทำ
• Compact
• Spray Control

• Ultra-compact, Low Flow Rate Flat Spray Nozzles

SCBIMV

Mean droplet diameter:20-100 μm
Spray capacity:0.25–4.0 L/hr
Spray angle:45°, 80°, 110°
Material:S303

• การสั่งทำ
• Compact
• Spray Control
• Suction

• Ultra-compact, Low Flow Rate Flat Spray Nozzles (Suction Type)

SCBIMV.S

Mean droplet diameter:20-30 μm
Spray capacity:0.1–0.74 L/hr
Spray angle:80°
Material:S303

• การสั่งทำ
• Ceramic Orifice
• Intermittent Pulse Spray
• Precision Guarantee
• Spray Control

• Pulse Spray Nozzles

SD-V

Operating pressure:0.05-0.9 MPa
Spray capacity:0.20–0.39 L/min (0.3 MPa)
Spray angle:49 - 114°
Material:S303

• Intermittent Pulse Spray
• Spray Control

• Pulse Spray Nozzles

SETO-SD

Mean droplet diameter:15–25 μm
Spray capacity:0.9–26.4 L/hr

• Clog Resistant
• High-viscosity Liquid Spray

• Full Cone Nozzles for Spraying Viscous Liquid

SETOJet

Mean droplet diameter:20–60 μm
Spray capacity:2.0–111 L/hr
Material:S303

• Clog Resistant
• Compact
• High-viscosity Liquid Spray

• Full Cone Nozzles for Spraying Viscous Liquid

SETO-SP

Mean droplet diameter:10–50 μm
Spray capacity:1.5–5.1 L/hr
Material:S303

• Clog Resistant
• Compact
• High-viscosity Liquid Spray

• Anti-dripping Flat Spray Nozzles

SETOV

Mean droplet diameter:15–40 μm
Spray capacity:1.7–10.6 L/hr
Material:S303

• Clog Resistant
• High-viscosity Liquid Spray

• Spray Pattern Adjustable Nozzles

SETOV-C

Spray capacity:1.0–30 L/hr
Material:S303

• Ceramic Orifice
• Precision Guarantee
• Spray Control

• Flat Spray Nozzles (with On-off Control)

SO-V

Operating pressure:0.05-0.5 MPa
Spray capacity:0.20–2.00 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• การสั่งทำ
• Precision Guarantee
• Spray Control

• Flat Spray Nozzles (with On-off Control)

SO-VV

Operating pressure:0.1-1 MPa
Spray capacity:0.50–1.00 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303

• Ceramic Orifice
• Precision Guarantee

• Flat Spray Nozzles (Three-piece Structure)

V

Operating pressure:0.05-2 MPa
Spray capacity:0.20–8.00 L/min (0.3 MPa)
Spray angle:50ﾟ, 65ﾟ, 80ﾟ, 90ﾟ, 115ﾟ
Material:S303

• Ceramic Orifice
• Precision Guarantee

• Flat Spray Nozzles

VP

Operating pressure:0.05-2 MPa
Spray capacity:0.20–8.00 L/min (0.3 MPa)
Spray angle:50ﾟ, 65ﾟ, 80ﾟ, 90ﾟ, 115ﾟ
Material:S303, B

• การสั่งทำ
• Precision Guarantee

• Flat Spray Nozzles

VV

Operating pressure:0.05-2 MPa
Spray capacity:0.50–20.0 L/min (0.3 MPa)
Spray angle:15ﾟ, 25ﾟ, 40ﾟ, 50ﾟ, 65ﾟ, 80ﾟ, 90ﾟ, 115ﾟ
Material:S303

• สินค้าสั่งทำ
• Precision Guarantee

• Flat Spray Nozzles

VVP

Operating pressure:0.05-2 MPa
Spray capacity:0.20–150 L/min (0.3 MPa)
Spray angle:15ﾟ, 25ﾟ, 40ﾟ, 50ﾟ, 65ﾟ, 80ﾟ, 90ﾟ, 115ﾟ
Material:S303, PP, PVDF

• Precision Guarantee

• Wide-angle Flat Spray Nozzles

YYP

Operating pressure:0.03-0.2 MPa
Spray capacity:0.30–250 L/min (0.3 MPa)
Spray angle:100°, 115°, 120°, 130°, 135°, 140°
Material:S303, PVC

• Compressor
• Spray Control
• With Caster Wheels

• Portable Spray Control Unit

FC Series (Portable Spray Controller)

Spray capacity:8 L/min (Max)
Air consumption:350 NL/min (Max)
Power consumption:21/18 W (50Hz/60Hz)
Operating pressure:S304
