Greenhouse and Livestock Farming
Spray nozzles are widely used across various agricultural sectors for applications such as pesticide spraying, mitigating damage from high temperatures, preventing pesticide drift on fields, safeguarding livestock from heatstroke, disinfection, deodorization, washing fish and other marine creatures at seafood processing facilities, and landscaping at sixth-industry restaurants and stores.
-
- Some Models are Made-to-Order
- Precision Guarantee
- Flat Spray Nozzles
VVP
Operating pressure:0.05-2 MPa
Spray capacity:0.20–150 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303, PP, PVDF
-
- Ceramic Orifice
- Precision Guarantee
- Hollow Cone Spray Nozzles
KB
Spray capacity:2.00–107 L/hr (0.7 MPa)
Mean droplet diameter:45–210 μm
Material:S303, B
Free passage diameter:0.15–0.60 mm
-
- Ceramic Orifice
- Precision Guarantee
- Hollow Cone Spray Nozzles
KBN
Spray capacity:2.00–7.25 L/hr (0.3 MPa)
Mean droplet diameter:35–60 μm
Material:Polyamide
Free passage diameter:0.2–0.4 mm
-
- Semi-Dry Fog
- Automated System for Cooling, Humidification, and Pest Control
CoolPescon
• Humidification function: for precise humidity (vapor-pressure deficit) control.
• Cooling function: suppressing temperature rise in a cultivation space.
• Chemical spray function: for foliar spray, disease prevention and control, pest prevention and control.
-
- Semi-Dry Fog
- Automated System for Cooling, Humidification, and Pest Control
CoolPescon
• Humidification function: for dust prevention and control.
• Cooling function: for alleviating heat stress for livestock.
• Chemical spray function: for disease control, pest prevention and control, and odor control.
-
- Blower
- Compressor
- Flexible Tubes
FT
Max. operating pressure:0.3 MPa
Heat resistance:65℃
Inlet thread size:R1/8, R1/4
Material:POM
-
- Semi-Dry Fog
- Water Savings
- Aeroponics Cultivation System
IKEUCHIPonics
• An aeroponics cultivation system that fills a root zone with a nutrient solution in fine fog form.
• The system, without having cultivation media or a liquid pool, enables direct fertilizer supply.
• Water usage is 3/4 of that used in rockwool cultivation.
-
- Precision Guarantee
- Quick-detachable
- Off-center Even Flat Spray Nozzles (Quick-detachable)
INOVVE
Operating pressure:0.15-0.7 MPa
Spray capacity:3.00-5.00 L/min (0.3 MPa)
Spray angle:45º
Material:Nozzle tip: PP, Adaptor: PP or PPS
-
- Ceramic Orifice
- Precision Guarantee
- Quick-detachable
- Flat Spray Nozzles (Quick-detachable)
INV
Operating pressure:0.05-2 MPa
Spray capacity:2.0–8.0 L/min (0.3 MPa)
Spray angle:50º, 65º, 80º, 90º, 115º
Material:S303
-
- Ceramic Orifice
- Precision Guarantee
- Quick-detachable
- Even Flat Spray Nozzles (Quick-detachable)
INVE
Operating pressure:0.05-2 MPa
Spray capacity:1.9–15.7 L/min (0.3 MPa)
Spray angle:15º, 25º, 40º, 50º, 65º, 80º, 90º, 115º
Material:S303
-
- Precision Guarantee
- Quick-detachable
- Flat Spray Nozzles (Quick-detachable)
INVV-SS (Stainless Steel)
Operating pressure:0.05-2 MPa
Spray capacity:1.50–20.0 L/min (0.3 MPa)
Spray angle:15º, 25º, 40º, 50º, 65º, 80º, 90º, 115º
Material:S303
-
- Ceramic Orifice
- Precision Guarantee
- Hollow Cone Spray Nozzles
KB
Spray capacity:2.00–107 L/hr (0.7 MPa)
Mean droplet diameter:45–210 μm
Material:S303, B
Free passage diameter:0.15–0.60 mm
-
- Ceramic Orifice
- Precision Guarantee
- Hollow Cone Spray Nozzles
KBN
Spray capacity:2.00–7.25 L/hr (0.3 MPa)
Mean droplet diameter:35–60 μm
Material:Polyamide
Free passage diameter:0.2–0.4 mm
-
- Precision Guarantee
- Off-center Even Flat Spray Nozzles
OVVEP
Operating pressure:0.05-2 MPa
Operating pressure:20.0-30.0 L/min (0.3 MPa)
Spray capacity:45º, 60º
Spray angle:S303
-
- Ball Joints for Connecting Spray Nozzles
UT
Max. operating pressure:1 MPa
Heat resistance:80℃
Outlet thread size:Rc1/8, Rc1/4
Material:FRPP
-
- Ball Joints for Connecting Spray Nozzles
UT (Metal)
Max. operating pressure:15 MPa
Heat resistance:120℃
Outlet thread size:Rc1/8–Rc3/4
Material:S303, B
-
- Ceramic Orifice
- Precision Guarantee
- Flat Spray Nozzles (Three-piece Structure)
V
Operating pressure:0.05-2 MPa
Spray capacity:0.20–8.00 L/min (0.3 MPa)
Spray angle:50°, 65°, 80°, 90°, 115°
Material:S303
-
- Ceramic Orifice
- Precision Guarantee
- Flat Spray Nozzles
VP
Operating pressure:0.05-2 MPa
Spray capacity:0.20–8.00 L/min (0.3 MPa)
Spray angle:50º, 65º, 80º, 90º, 115º
Material:S303, B, PVDF
-
- Made-to-Order
- Precision Guarantee
- Flat Spray Nozzles
VV
Operating pressure:0.05-2 MPa
Spray capacity:0.50–20.0 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303
-
- Some Models are Made-to-Order
- Precision Guarantee
- Flat Spray Nozzles
VVP
Operating pressure:0.05-2 MPa
Spray capacity:0.20–150 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°fog
Material:S303, PP, PVDF
