Pollution Control and Petrochemicals
Our spray nozzles remove dioxins, nitrogen oxides, and sulfur oxides generated in waste incineration plants and chemical plants. Proper removal of these hazardous substances enables the release of processed clean air and water.
-
- Some Models are Made-to-Order
- Precision Guarantee
- Flat Spray Nozzles
VVP
Operating pressure:0.05-2 MPa
Spray capacity:0.20–150 L/min (0.3 MPa)
Spray angle:15°, 25°, 40°, 50°, 65°, 80°, 90°, 115°
Material:S303, PP, PVDF
-
- Ceramic Orifice
- Precision Guarantee
- Hollow Cone Spray Nozzles
KB
Spray capacity:2.00–107 L/hr (0.7 MPa)
Mean droplet diameter:45–210 μm
Material:S303, B
Free passage diameter:0.15–0.60 mm
-
- Precision Guarantee
- Hollow Cone Spray Nozzles
AAP
Spray capacity:1.00–23.0 L/min (0.2 MPa)
Spray angle:75–80º
Material:S304
Free passage diameter:2.0–8.0 mm
-
- Made-to-Order
- Precision Guarantee
- Spray Nozzles for Spraying Slurries
TAA
Spray capacity:200–1,200 L/min (0.07 MPa)
Spray angle:67–80º
Material:SiC
Free passage diameter:28–68 mm
-
- Some Models are Made-to-Order
- Precision Guarantee
- Full Cone Spray Nozzles
JJXP
Spray capacity:0.50–1200 L/min (0.2 MPa)
Spray angle:55–105º
Material:S303, S316
Free passage diameter:0.4–20.0 mm
-
- Precision Guarantee
- Full Cone Spray Nozzles (Clog-resistant)
AJP
Spray capacity:2.00–250 L/min (0.2 MPa)
Spray angle:75º, 80º, 85º, 90º
Material:S303, S304, SCS13
Free passage diameter:1.6–22.3 mm
-
- Spray Control
- Spray Gun Unit with BIM Nozzles
BIMV
Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:45º, 80º, 110º
Material:S303
-
- Spray Control
- Fine Fog, Full Cone Spray Nozzles
BIMJ
Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70º, 20º
Material:S303
-
- Clog Resistant
- High-viscosity Liquid Spray
- Full Cone Nozzles for Spraying Viscous Liquid
SETOJet
Mean droplet diameter:20–60 μm
Spray capacity:2.0–111 L/hr
Material:S303
-
- Lengthening Repair Intervals for Refractories
Kiln Shell Cooling System
• Extends the service life of the kiln shell and its refractory bricks.
• Ensures long-term continuous and stable operation of the kiln.
• Stabilizes the internal coating.
• Controls the temperature of the kiln.
-
- Made-to-Order
- Precision Guarantee
- Seven-head Full Cone Spray Nozzles
7JJXP
Spray capacity:7.00–315 L/min (0.2 MPa)
Spray angle:175–215º
Material:S303
Free passage diameter:0.8–4.7 mm
-
- Precision Guarantee
- Seven-head Full Cone Spray Nozzles
7KB
Spray capacity:0.23–10.9 L/min (0.7 MPa)
Spray angle:180º
Material:S303
Free passage diameter:0.15–0.60 mm
-
- Made-to-Order
- 7-outlet Connecting Adaptor
7-outlet Adaptor
Max. operating pressure:1.0 MPa
Heat resistance:80℃
Outlet thread size:Rc1/8
Material:FRPP
-
- Precision Guarantee
- Hollow Cone Spray Nozzles
AAP
Spray capacity:1.00–23.0 L/min (0.2 MPa)
Spray angle:75–80º
Material:S304
Free passage diameter:2.0–8.0 mm
-
- Dry Fog
- Pneumatic Humidification
- Dry Fog Humidifier
AKIMist "E"
Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–4.5 L/hr (per nozzle)
Air consumption:22–54 NL/min (per nozzle)
-
- Dry Fog
- Pneumatic Humidification
- With Caster Wheels
- Portable Dry Fog Humidifier Set
AE-T Set
Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–14.4 L/hr (03C)
Air consumption:22–172 NL/min (03C)
-
- Dry Fog
- Pneumatic Humidification
- Industrial Humidification System
AirAKI
Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–4.5 L/hr (per nozzle)
Air consumption:22–54 NL/min (per nozzle)
-
- Hydraulic Humidification
- Semi-Dry Fog
- Humidification System for Industrial Use
AirULM
• Hydraulic humidification system to humidify an entire factory space
• Operates solely with a high-pressure pump without using compressed air.
• Lower operating costs compared to other humidification approaches.
-
- Precision Guarantee
- Full Cone Spray Nozzles (Clog-resistant)
AJP
Spray capacity:2.00–250 L/min (0.2 MPa)
Spray angle:75º, 80º, 85º, 90º
Material:S303, S304, SCS13
Free passage diameter:1.6–22.3 mm
-
- Made-to-Order
- Precision Guarantee
- Full Cone Spray Nozzles (Alumina Ceramic)
AJP-AL92
Spray capacity:18.0–250 L/min (0.2 MPa)
Spray angle:85º, 90º
Material:92％ Alumina
Free passage diameter:5.1–21.3 mm
-
- Made-to-Order
- Impinging-type Fine Fog Nozzles
AKIJet
Mean droplet diameter:10–120 μm
Spray capacity:10–450 L/hr
Spray width:140–780 mm
Material:S303 equivalent, S303, SCS14, S316
-
- Made-to-Order
- Precision Guarantee
- Hollow Cone Spray Nozzles (Alumina Ceramic)
AP-AL92
Spray capacity:14.0–600 L/min (0.2 MPa)
Spray angle:80º, 85º
Material:92％ Alumina
Free passage diameter:6.8–39.6 mm
-
- ARS Filter
- Filtration Device
- Automatic Strainer
ARS (Auto Reverse Self-cleaning Filter)
Max. filtration capacity:150–2,500 L/min
Types of screen:Metal wire screen , Wedge wire screen
-
- Hydraulic Humidification
- Semi-Dry Fog
- Humidification System for Office Use
AU-KIT
• Eliminates the hassle of daily water refilling tasks with an automatic water supply function.
• Reduces the formation of white powder around the humidifiers.
• Enables automatic operation with a humidity- or timer-controller.
-
- Made-to-Order
- Clog Resistant
- Fine Fog, Flat Spray Nozzles (Large Capacity)
BAVV
Mean droplet diameter:30–100 μm
Spray capacity:9.0–123 L/hr
Spray angle:60º
Material:S303, S304
-
- Spray Control
- Fine Fog, Full Cone Spray Nozzles
BIMJ
Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70º, 20º
Material:S303
-
- Spray Control
- Fine Fog, Hollow Cone Spray Nozzles
BIMK
Mean droplet diameter:20-100 μm
Spray capacity:2.0–107 L/hr
Spray angle:60º
Material:S303
-
- Spray Control
- Suction
- Fine Fog, Hollow Cone Spray Nozzles (Suction Type)
BIMK-S
Mean droplet diameter:20-30 μm
Spray capacity:1.4–5.5 L/hr
Spray angle:60º
Material:S303
-
- Spray Control
- Spray Gun Unit with BIM Nozzles
BIMV
Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:45º, 80º, 110º
Material:S303
-
- Spray Control
- Suction
- Fine Fog, Flat Spray Nozzles (Suction Type)
BIMV-S
Mean droplet diameter:20-30 μm
Spray capacity:0.5–5.5 L/hr
Spray angle:80º
Material:S303
-
- Spray Gun Unit with BIM Nozzles
BIM-GUN
-
- Compact
- Spray Control
- Fine Fog, Flat Spray Nozzles
CBIMJ
Mean droplet diameter:20-100 μm
Spray capacity:0.25–38.5 L/hr
Spray angle:20º
Material:S303
-
- Compact
- Spray Control
- Fine Fog, Hollow Cone Spray Nozzles
CBIMK
Mean droplet diameter:20-100 μm
Spray capacity:2.0–38.5 L/hr
Spray angle:60º
Material:S303
-
- Compact
- Spray Control
- Suction
- Fine Fog, Hollow Cone Spray Nozzles (Suction Type)
CBIMK-S
Mean droplet diameter:20-30 μm
Spray capacity:1.4–5.5 L/hr
Spray angle:60º
Material:S303
-
- Compact
- Spray Control
- Fine Fog, Flat Spray Nozzles
CBIMV
Mean droplet diameter:20-100 μm
Spray capacity:0.25–38.5 L/hr
Spray angle:45º, 80º, 110º
Material:S303
-
- Compact
- Spray Control
- Suction
- Fine Fog, Flat Spray Nozzles (Suction Type)
CBIMV-S
Mean droplet diameter:20-30 μm
Spray capacity:0.1–5.5 L/hr
Spray angle:80º
Material:S303
-
- Clog Resistant
- Flat Spray Nozzles
DOVVA-G
Mean droplet diameter:80–120 μm
Spray capacity:1.0–50 L/min
Spray angle:55º, 70º
Material:S316L, S304
-
- Blower
- Compressor
- Flexible Tubes
FT
Max. operating pressure:0.3 MPa
Heat resistance:65℃
Inlet Thread Size:Rc1/8, Rc1/4
Material:POM
-
- Large Capacity Fine Fog Spray Nozzles (Large Spray Capacity)
GSIMⅡ
Mean droplet diameter:40–80 μm
Spray capacity:15–2,000 L/hr
Spray angle:20º, 60º
Material:S316L, S303
-
- Return-flow Nozzle
- Spillback Nozzles
GSPB
Supply pressure:1.0–4.0 MPa
Spray angle:90–130º
Material:Stainless steel (Nozzle tip: Tungsten carbide)
Free passage diameter:5.7 mm
-
- Downstream Fogging
- Upstream Fogging
- Wet Compression
- Recovering Diminished Power Output
GT Inlet Air Cooling System
• Recovers the diminished power output in summertime.
• The system is optionally available for upstream or downstream fogging, or wet compression.
• A simulation analysis or an evaporative experiment is available at optional costs.
-
- Precision Guarantee
- Quick-detachable
- Full Cone Spray Nozzles (Quick-detachable)
INJJX-SS
Spray capacity:1.00–6.00 L/min (0.2 MPa)
Spray angle:55º, 65º,70º, 75º
Material:S303
Free passage diameter:0.7–1.7 mm
-
- Precision Guarantee
- Quick-detachable
- Flat Spray Nozzles (Quick-detachable)
INVV-SS (Stainless Steel)
Operating pressure:0.05-2 MPa
Spray capacity:1.50–20.0 L/min (0.3 MPa)
Spray angle:15º, 25º, 40º, 50º, 65º, 80º, 90º, 115º
Material:S303
-
- Clog Resistant
- Full Cone Spray Nozzles
JJA
Mean droplet diameter:150–650 μm
Spray capacity:1.1–24.0 L/min
Material:S316L, S304
-
- Full Cone Spray Nozzles
JJHP
Spray capacity:340–840 L/min (0.05 MPa)
Spray angle:75–105º
Material:S316L
Free passage diameter:10–15.5 mm
-
- Some Models are Made-to-Order
- Precision Guarantee
- Full Cone Spray Nozzles
JJXP
Spray capacity:0.50–1200 L/min (0.2 MPa)
Spray angle:55–105º
Material:S303, S316
Free passage diameter:0.4–20.0 mm
-
- Precision Guarantee
- Full Cone Spray Nozzles
JJXP-PVDF
Spray capacity:1.00–3.00 L/min (0.2 MPa)
Spray angle:65º
Material:PVDF
Free passage diameter:0.8–1.5 mm
-
- Steam
- Steam-driven Spray Nozzles
JOKIJet
Spray capacity:10–1,200 L/hr
Material:S316L, S304
-
- Made-to-Order
- Ceramic Orifice
- Precision Guarantee
- Full Cone Spray Nozzles
JUP
Spray capacity:3.00-90.0 L/min (0.2 MPa)
Spray angle:60-85º
Material:S303, S316
Free passage diameter:1.2-5.0 mm
-
- Made-to-Order
- Precision Guarantee
- Full Cone Spray Nozzles (Alumina Ceramic)
JUXP-AL92
Spray capacity:23.0–700 L/min (0.2 MPa)
Spray angle:75–100º
Material:92％ Alumina
Free passage diameter:4.7–17.8 mm
