• Spray Control

• Humidity Controller

RHC-C11

・Controls automatic operation of Dry Fog humidifier
・Includes one humidity sensor per unit
・Operates on 100-240 VAC

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles

KB

Spray capacity:2.00–107 L/hr (0.7 MPa)
Mean droplet diameter:45–210 μm
Material:S303, B
Free passage diameter:0.15–0.60 mm

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles

KBN

Spray capacity:2.00–7.25 L/hr (0.3 MPa)
Mean droplet diameter:35–60 μm
Material:Polyamide
Free passage diameter:0.2–0.4 mm

• Spray Control

• Spray Gun Unit with BIM Nozzles

BIMV

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:45º, 80º, 110º
Material:S303

• Spray Control

• Fine Fog, Full Cone Spray Nozzles

BIMJ

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70º, 20º
Material:S303

• Dry Fog
• Pneumatic Humidification

• Dry Fog Humidifier

AKIMist "E"

Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–4.5 L/hr (per nozzle)
Air consumption:22–54 NL/min (per nozzle)

• Dry Fog
• Pneumatic Humidification
• With Caster Wheels

• Portable Dry Fog Humidifier Set

AE-T Set

Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–14.4 L/hr (03C)
Air consumption:22–172 NL/min (03C)

• Universal Adaptors for AKIMist-E

AE-UT Adaptor

Material:POM

• Dry Fog
• Pneumatic Humidification

• Industrial Humidification System

AirAKI

Humidification method:Pneumatic humidification
Operating pressure:0.2–0.5 MPa
Humidification capacity:1.3–4.5 L/hr (per nozzle)
Air consumption:22–54 NL/min (per nozzle)

• Dry Fog
• Hydraulic Humidification
• Pneumatic Humidification
• Semi-Dry Fog

• Hybrid Humidification System

AirHYBRID

• A composite system that utilizes both hydraulic and pneumatic humidification
• The hydraulic humidification establishes the base level of humidity.
• The pneumatic system provides localized humidification where needed.

• Hydraulic Humidification
• Semi-Dry Fog

• Humidification System for Industrial Use

AirULM

• Hydraulic humidification system to humidify an entire factory space
• Operates solely with a high-pressure pump without using compressed air.
• Lower operating costs compared to other humidification approaches.

• Made-to-Order

• Impinging-type Fine Fog Nozzles

AKIJet

Mean droplet diameter:10–120 μm
Spray capacity:10–450 L/hr
Spray width:140–780 mm
Material:S303 equivalent, S303, SCS14, S316

• Hydraulic Humidification
• Semi-Dry Fog

• Humidification System for Office Use

AU-KIT

• Eliminates the hassle of daily water refilling tasks with an automatic water supply function.
• Reduces the formation of white powder around the humidifiers.
• Enables automatic operation with a humidity- or timer-controller.

• Spray Control

• Fine Fog, Full Cone Spray Nozzles

BIMJ

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:70º, 20º
Material:S303

• Spray Control

• Fine Fog, Hollow Cone Spray Nozzles

BIMK

Mean droplet diameter:20-100 μm
Spray capacity:2.0–107 L/hr
Spray angle:60º
Material:S303

• Spray Control

• Spray Gun Unit with BIM Nozzles

BIMV

Mean droplet diameter:20-100 μm
Spray capacity:1.0–107 L/hr
Spray angle:45º, 80º, 110º
Material:S303

• Misting Kit with Tap Water Connection

COOLKIT-A

Spray capacity:19 L/hr (0.2 MPa)
Number of nozzles:5 nozzles
Tube length:10m (Water supply tubing)

• Misting Kit with Tap Water Connection (High Pressure Type)

COOLKIT-D

Spray capacity:17.0 L/hr (5.0 MPa)
Number of nozzles:8 nozzles
Tube length:15m (High pressure tube)

• Air Conditioning Unit
• Dry Fog
• Humidification inside Duct
• Pneumatic Humidification

• Humidification System for Cleanroom

HandAKI

Method:Pneumatic humidification
Application 1: Humidification in cleanrooms
Application 2: Humidification in biological cleanrooms
Application 3: Humidification in fermentation rooms and printing booths

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles (Three-piece Structure)

K

Spray capacity:0.06-1.80 L/min (0.3 MPa)
Mean droplet diameter:80-380 μm
Material:S303
Free passage diameter:0.4-1.7 mm

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles

KB

Spray capacity:2.00–107 L/hr (0.7 MPa)
Mean droplet diameter:45–210 μm
Material:S303, B
Free passage diameter:0.15–0.60 mm

• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles

KBN

Spray capacity:2.00–7.25 L/hr (0.3 MPa)
Mean droplet diameter:35–60 μm
Material:Polyamide
Free passage diameter:0.2–0.4 mm

• Made-to-Order
• Ceramic Orifice
• Precision Guarantee

• Hollow Cone Spray Nozzles (Three-piece Structure)

KD

Spray capacity:0.30–3.94 L/min (0.3 MPa)
Spray angle:70–97º
Material:S303
Free passage diameter:0.7–1.8 mm

• Some Models are Made-to-Order
• Precision Guarantee

• Hollow Cone Spray Nozzles

KKBP

Spray capacity:0.50–2.00 L/min (0.3 MPa)
Spray angle:53–68º
Material:S303
Free passage diameter:1.0–1.8 mm

• Ceramic Orifice
• Precision Guarantee
• Spray Control

• Flat Spray Nozzles (with On-off Control)

SO-V

Operating pressure:0.05-0.5 MPa
Spray capacity:0.20–2.00 L/min (0.3 MPa)
Spray angle:15º, 25º, 40º, 50º, 65º, 80º, 90º, 115º
Material:S303

• Made-to-Order
• Precision Guarantee
• Spray Control

• Flat Spray Nozzles (with On-off Control)

SO-VV

Operating pressure:0.1-1 MPa
Spray capacity:0.50–1.00 L/min (0.3 MPa)
Spray angle:15º, 25º, 40º, 50º, 65º, 80º, 90º, 115º
Material:S303

• Compressor
• Steam

• Flat Air Nozzles

VZ

Air consumption:154–1,122 NL/min (0.3 MPa)
Max. operating pressure:0.7 MPa
Noise level:84 dBA
Material:S303
